2SB772

SKU: 6341

Manufacturer: STMicroelectronics

Trans GP BJT PNP 30V 3A 12500mW 3-Pin(3+Tab) SOT-32 Tube

3780 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8541.29.00.95
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Type	PNP
Product Category	Bipolar Power
Configuration	Single
Number of Elements per pcs	1
Collector Base Voltage-Max (V)	60
Collector-Emitter Voltage-Max (V)	30
Maximum Emitter Base Voltage (V)	5
Maximum Base Emitter Saturation Voltage (V)	1.2@100mA@2A
Maximum Collector-Emitter Saturation Voltage (V)	0.7@100mA@2A
Maximum DC Collector Current (A)	3
Minimum DC Current Gain	100@100mA@2V
Maximum Power Dissipation (mW)	12500
Maximum Transition Frequency (MHz)	100(Typ)
Operating Temperature-Min	-65
Operating Temperature-Max	150
Packing Method	Tube
Original Package	SOT-32
Pin Count	3
Standard Package Method	TO-126
Terminal Form	Through Hole
Package Height	10.8(Max)
Package Length	7.8(Max)
Package Width	2.7(Max)
PCB changed	3
Tab	Tab
