    A2410

    SKU: 38655
    Manufacturer: Sensata Technologies
    Solid State Relay 4mA 280V AC-IN 10A 280V AC-OUT 4-Pin
    1200 parts IN STOCK
    Shipped from :
    Netherlands
    Expected Ships :
    Rohs State : Need to verify

    QUANTITY

    Increments of 0 pcs
    Products specifications
    EU RoHS Compliant with Exemption
    ECCN (US) EAR99
    Part Status Active
    Automotive No
    PPAP No
    Input Type AC
    Minimum Input Voltage (V) 90(RMS)
    Maximum Input Voltage (V) 280(RMS)
    Maximum Input Current (mA) 4(Typ)
    Maximum Output Voltage (V) 280(RMS)
    Maximum Output Current (A) 10(RMS)
    Output Device SCR
    Output Type AC
    I/O Isolation Voltage (V) 4000(RMS)
    Circuit Arrangement 1 Form A
    Operating Temperature-Min -40
    Operating Temperature-Max 80
    Pin Count 4
    Terminal Form Screw
    Package Height 23.3
    Package Length 57.3
    Package Width 44.5
