3403.0283.23 Schurter

3403.0283.23

SKU: 86355

Manufacturer: Schurter

Fuse Chip Slow Blow Acting 8A 277V SMD Solder Pad 16 X 5.3mm Ceramic T/R Automotive UL/VDE

Request Free Samples

2630 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	Yes
PPAP	Unknown
Type	Chip
Acting	Slow Blow
Application	Explosion Protection
Fuse Size (mm)	16 X 5.3
Current Rating (A)	8
Voltage Rating (V)	277
Maximum AC Voltage Rating (V)	277
Maximum DC Voltage Rating (V)	250
Maximum Power Dissipation (W)	1.25(Typ)
Typical Melting I2t (A²S)	95
Terminal Form	Solder Pad
Number of Terminals	2
Operating Temperature-Min	-55
Operating Temperature-Max	125
Packing Method	Tape and Reel
Product Weight (g)	1.42
Depth (mm)	5.35
Length (mm)	15.4
Height (mm)	5.35
Fuse Body Material	Ceramic
