3402.0040.22

SKU: 65204

Manufacturer: Schurter

Fuse Chip Fast Acting 10A 63V SMD Solder Pad 7.4 X 3.1 X 2.6mm Thermoplastic T/R CSA/UL

2930 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Type	Chip
Acting	Fast
Application	Primary Protection on SMD PCB
Fuse Size (mm)	7.4 X 3.1 X 2.6
Current Rating (A)	10
Voltage Rating (V)	63
Maximum AC Voltage Rating (V)	63
Maximum DC Voltage Rating (V)	63
Maximum Power Dissipation (W)	0.8(Typ)
Typical Melting I2t (A²S)	54
Terminal Form	Solder Pad
Number of Terminals	2
Operating Temperature-Min	-55
Operating Temperature-Max	125
Packing Method	Tape and Reel
Depth (mm)	3.1
Length (mm)	7.4
Height (mm)	2.6
Fuse Body Material	Thermoplastic
Terminal Form	Surface Mount
