ESQ-132-14-G-D

SKU: 51739

Manufacturer: Samtec

Conn Elevated Socket SKT 64 POS 2.54mm Solder ST Top Entry Thru-Hole Tube

3790 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8536.69.40.40
Automotive	No
PPAP	No
Type	Elevated Socket
Gender	SKT
Number of Contacts	64
Number of Rows	2
Termination Method	Solder
Terminal Pitch (mm)	2.54
Body Orientation	Straight
Row Spacing (mm)	2.54
Current Rating-Max(A)	5.7/Contact
Voltage Rating-Max	550VAC
Maximum Contact Resistance (mOhm)	10
Operating Temperature-Min	-55
Operating Temperature-Max	125
Mating Cycle (Cycles)	100
Packing Method	Tube
Length (mm)	81.79
Depth (mm)	4.95
Height (mm)	11.05
Tail Length (mm)	12.2
