RP118Z301D-TR-F

SKU: 21116

Manufacturer: Ricoh Electronic Devices Company

LDO Regulator Pos 3V 0.1A 4-Pin WLCSP-P4 T/R

2480 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Automotive	No
PPAP	No
Type	LDO
Number of Outputs	1
Polarity	Positive
Accuracy (%)	±1
Output Type	Fixed
Output Voltage (V)	3
Maximum Output Current (A)	0.1(Min)
Minimum Input Voltage (V)	1.7
Maximum Input Voltage (V)	5.5
Maximum Dropout Voltage @ Current (V)	0.16@150mA
Line Regulation	0.2%/V
Load Regulation	40mV
Maximum Power Dissipation (mW)	470
Junction to Ambient	212°C/W
Special Features	Current Limit
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tape and Reel
Original Package	WLCSP-P4
Pin Count	4
Terminal Form	Surface Mount
Package Height	0.31
Package Length	0.64
Package Width	0.64
