R1173S191B-E2-FE

SKU: 42365

Manufacturer: Ricoh Electronic Devices Company

LDO Regulator Pos 1.9V 1A Automotive 6-Pin HSOP-J T/R

4100 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Unconfirmed
Automotive	Unknown
PPAP	Unknown
Type	LDO
Number of Outputs	1
Polarity	Positive
Accuracy (%)	±2
Output Type	Fixed
Output Voltage (V)	1.9
Maximum Output Current (A)	1(Min)
Minimum Input Voltage (V)	1.4
Maximum Input Voltage (V)	6
Maximum Dropout Voltage @ Current (V)	0.15@300mA
Line Regulation	0.2%/V
Load Regulation	15mV
Maximum Power Dissipation (mW)	1700
Special Features	Current Limit
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tape and Reel
Original Package	HSOP-J
Pin Count	6
Terminal Form	Surface Mount
Package Height	1.5
Package Length	5.02
Package Width	3.9
