RP15-2405SFW RECOM Power

RP15-2405SFW

SKU: 144122

Manufacturer: RECOM Power

Module DC-DC 24VIN 1-OUT 5V 3A 15W 4-Pin Tube

Download sample

Request Free Samples

1740 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8504.40.95.80
Automotive	No
PPAP	No
Type	Step Down
Number of Outputs	1
Isolation	Isolated
Minimum Input Voltage (V)	9
Typical Input Voltage (V)	24
Maximum Input Voltage (V)	36
Output Voltage (V)	5
Output Current (A)	3
Output Power (W)	15
Minimum Isolation Voltage	1600VDC
Input/Output Type	DC/DC
Typical Standby Current (mA)	2.5
Switching Frequency (kHz)	440
Switching Regulator	Yes
Load Regulation	0.5%
Line Regulation	0.2%
Efficiency (%)	87(Typ)
Operating Temperature-Min	-40
Operating Temperature-Max	105
Packing Method	Tube
Product Weight (g)	27
Output Type	Fixed
Pin Count	4
Terminal Form	Through Hole
Package Height	10.2
Package Length	25.4
Package Width	50.8
PCB changed	4
