ELL-6UH101M

SKU: 93877

Manufacturer: Panasonic

Power Choke Shielded Wirewound 100uH 20% 100KHz 0.6A 0.36Ohm DCR T/R

990 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8504.50.80.00
Automotive	No
PPAP	No
Type	Power Choke
Technology	Wirewound
Protection Style	Shielded
Inductance (H)	100u
Tolerance	20%
Inductance Test Frequency (Hz)	100K
Maximum DC Current (A)	0.6
Maximum Saturation Current (A)	0.6
Maximum DC Resistance (Ohm)	0.36(Typ)
Number of Terminals	2
Packing Method	Tape and Reel
Length (mm)	6.9
Terminal Form	Surface Mount
Depth (mm)	6.5
