ELC-09D102F

SKU: 32855

Manufacturer: Panasonic

Choke Wirewound 1000uH 10% 10KHz Ferrite 0.28A 2.1Ohm DCR RDL

760 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8504.50.80.00
Automotive	No
PPAP	No
Type	Choke
Technology	Wirewound
Core Body Material	Ferrite
Inductance (H)	1000u
Tolerance	10%
Inductance Test Frequency (Hz)	10K
Maximum DC Current (A)	0.28
Maximum Saturation Current (A)	0.28
Maximum DC Resistance (Ohm)	2.1(Typ)
Terminal Form	Through Hole
Lead Style	Radial
Terminal Pitch (mm)	5
Number of Terminals	2
Product Diameter (mm)	9.5
