ALE1PB05

SKU: 102575

Manufacturer: Panasonic

Power Relay 5VDC 16A SPST-NO(28.6x12.4x24.9)mm THT

2360 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8536.49.00.75
Automotive	No
PPAP	No
Contact Arrangement	SPST-NO
Contact Form	1 Form A
DC Coil Voltage (V)	5
Coil Current (mA)	80
Coil Resistance (Ohm)	63
Insulation Resistance (MOhm)	1000(Min)
Maximum Contact Resistance (mOhm)	100
Maximum Pick-Up Voltage	3.75VDC
Minimum Dropout Voltage	0.25VDC
Maximum AC Switching Voltage (V)	277
Maximum Switching Current (A)	16
Maximum Switching Power	4.432kVA
Operate Time (ms)	20
Release Time (ms)	20
Electrical Life (Operations)	100000
Mechanical Life (Operations)	2000000
LED Indicator	No
Push to Test Button	No
Coil Suppression Diode	No
Relay Construction	Non-Latching
Terminal Form	Through Hole
Terminal Form	PC Pin
Number of Terminals	4
Operating Temperature-Min	-40
Operating Temperature-Max	85
Product Weight (g)	15
Length (mm)	28.6
Depth (mm)	12.4
