LCWW5AM-KXKY-4U8X OSRAM Opto Semiconductors

LCWW5AM-KXKY-4U8X

SKU: 40520

Manufacturer: OSRAM Opto Semiconductors

LED Uni-Color White 2700K 80 2-Pin SMD T/R

Download sample

Request Free Samples

1120 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
Automotive	No
PPAP	No
Type	Uni-Color
Product Category	Chip LED
Color	White
Number of LEDs	1
LED Body Material	InGaN
Lens Shape Type	Circular
Lens Dimensions (mm)	5x5x1.2
Lens Appearance	Colorless Non Diffused
Mounting Orientation	Top Mount
Luminous Flux	97lm(Max)
Intensity	22000mcd
Viewing Angle (°)	170
Maximum Forward Current (mA)	1000
Test Current (mA)	350
Maximum Forward Voltage (V)	3.7
Operating Temperature-Min	-40
Operating Temperature-Max	125
Color Temperature	2700K
Lead Standoff	No
Supplier Color	White
Color Rendering Index	80
High Power	Yes
High Brightness	Yes
Packing Method	Tape and Reel
Original Package	SMD
Pin Count	2
Standard Package Method	SMD
Terminal Form	Surface Mount
Package Height	3.1(Max)
Package Length	7.2(Max)
Package Width	6.2(Max)
PCB changed	2
