    SN74LS04N

    SKU: 113619
    Manufacturer: onsemi
    Inverter 6-Element Bipolar 14-Pin PDIP Box
    Download sample
    Request Free Samples
    17580 parts IN STOCK
    Shipped from :
    Netherlands
    Expected Ships :
    Rohs State : Need to verify

    QUANTITY

    Increments of 0 pcs
    Products specifications
    EU RoHS Not Compliant
    ECCN (US) EAR99
    Part Status Obsolete
    HTS 8542.39.00.01
    SVHC Yes
    SVHC Exceeds Threshold Yes
    Automotive No
    PPAP No
    Logic Family LS
    Logic Function Inverter
    Number of Elements per pcs 6
    Maximum Propagation Delay Time @ Maximum CL (ns) 15@5V
    Absolute Propagation Delay Time (ns) 15
    Process Technology Bipolar
    Maximum Low Level Output Current (mA) 8
    Maximum High Level Output Current (mA) -0.4
    Operating Supply Voltage-Min (V) 4.75
    Typical Operating Supply Voltage (V) 5
    Operating Supply Voltage-Max (V) 5.25
    Propagation Delay Test Condition (pF) 15
    Operating Temperature-Min 0
    Operating Temperature-Max 70
    Packing Method Box
    Original Package PDIP
    Pin Count 14
    Standard Package Method DIP
    Terminal Form Through Hole
    Package Height 4.95(Max)
    Package Length 19.69(Max)
    Package Width 7.11(Max)
    PCB changed 14
