CAT24C04ZI-G

SKU: 103048

Manufacturer: onsemi

EEPROM Serial-2Wire 4K-bit 512 x 8 1.8V/2.5V/3.3V/5V 8-Pin MSOP

1470 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8542.32.00.51
Automotive	No
PPAP	No
Chip Density (bit)	4K
Organization	512x8
Programmability	Yes
Data Retention (Year)	100(Min)
Max. Access Time (ns)	900
Maximum Operating Frequency (MHz)	0.4
Interface Type	Serial-2Wire
Operating Supply Voltage-Min (V)	1.7
Typical Operating Supply Voltage (V)	5
Operating Supply Voltage-Max (V)	5.5
Operating Current (mA)	2
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Industrial
Hardware Data Protection	Yes
Pin Count	8
Standard Package Method	SOP
Original Package	MSOP
Terminal Form	Surface Mount
Package Height	0.85
Package Length	3
Package Width	3
PCB changed	8
