BST-15/100-D48-C Murata Power Solutions

BST-15/100-D48-C

SKU: 23055

Manufacturer: Murata Power Solutions

Module DC-DC 48VIN 2-OUT 15V/-15V 0.1A/-0.1A 3W 8-Pin PDIP

Download sample

Request Free Samples

3180 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	NRND
HTS	8504.40.95.80
Automotive	No
PPAP	No
Type	Non-Inverting
Number of Outputs	2
Isolation	Isolated
Minimum Input Voltage (V)	18
Typical Input Voltage (V)	48
Maximum Input Voltage (V)	72
Output Voltage (V)	15
Output Current (A)	0.1
Output Power (W)	3
Minimum Isolation Voltage	1000VDC
Input/Output Type	DC/DC
Switching Frequency (kHz)	200(Typ)
Switching Regulator	Yes
Load Regulation	0.5%
Line Regulation	0.5%
Efficiency (%)	77(Typ)
Operating Temperature-Min	-40
Operating Temperature-Max	75
Product Weight (g)	14.2
Output Type	Fixed
Original Package	PDIP
Pin Count	8
Standard Package Method	DIP
Terminal Form	Through Hole
Package Height	11.43
Package Length	31.75
Package Width	20.32
PCB changed	8
