85502-5005

SKU: 93417

Manufacturer: Molex

Conn RJ-11 F 4 POS 1.27mm Solder RA SMD 4 Terminal 1 Port Cat 3 T/R

1430 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
SVHC	Yes
Automotive	No
PPAP	No
Type	RJ-11
Gender	F
Number of Terminals	4
Number of Contacts	4
Number of Ports	1
Number of Loaded Positions	4
Category Number	Cat 3
Termination Method	Solder
Terminal Pitch (mm)	1.27
Body Orientation	Right Angle
Current Rating-Max(A)	1.5/Contact
Voltage Rating-Max	125VDC
Maximum Contact Resistance (mOhm)	20
Mating Cycle (Cycles)	2500
Integrated Magnetics	No
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tape and Reel
Product Style	Single
Product Weight (g)	1.867
Length (mm)	14.13
Depth (mm)	18.1
Height (mm)	11.5
