SMBJ5337BE3/TR13

SKU: 35686

Manufacturer: Microchip Technology

Zener Diode Single 4.7V 5% 2Ohm 5000mW 2-Pin SMB T/R

3430 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8541.10.00.50
Automotive	No
PPAP	No
Type	Voltage Regulator
Configuration	Single
Nominal Zener Voltage (V)	4.7
Zener Voltage Tolerance	5%
Maximum Voltage Regulation (mV)	440
Maximum Power Dissipation (mW)	5000
Test Current (mA)	260
Maximum Reverse Leakage Current (uA)	5
Maximum Regulator Current (mA)	1010
Maximum Zener Impedance (Ohm)	2
Maximum Power Dissipation @ 25C (mW)	5000
Operating Temperature-Min	-65
Operating Temperature-Max	150
Packing Method	Tape and Reel
Original Package	SMB
Pin Count	2
Standard Package Method	DO-214-AA
Terminal Form	Surface Mount
Package Length	4.57(Max)
Package Width	3.94(Max)
PCB changed	2
