PIC24HJ12GP201-I/SO

SKU: 63610

Manufacturer: Microchip Technology

MCU 16-bit PIC RISC 12KB Flash 3.3V Automotive 18-Pin SOIC W Tube

2150 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	3A991.a.2
Part Status	Active
HTS	8542.31.00.01
Automotive	Yes
PPAP	Yes
Family Name	PIC24
Instruction Set Architecture	RISC
Device Core	PIC
Core Architecture	PIC
Maximum CPU Frequency (MHz)	40
Maximum Clock Rate (MHz)	40
Data Bus Width (bit)	16
Program Memory Type	FLASH
Program Memory Size	12KB
RAM Size	1KB
Maximum Expanded Memory Size	12MB
Programmability	Yes
Interface Type	I2C/SPI/UART
Number of I/Os	13
No. of Timers	3
PWM	2
Number of ADCs	Single
ADC Channels	6
ADC Resolution (bit)	12
USART	0
UART	1
USB	0
SPI	1
I2C	1
I2S	0
CAN	0
Ethernet	0
Watchdog	1
Operating Supply Voltage-Min (V)	3
Typical Operating Supply Voltage (V)	3.3
Operating Supply Voltage-Max (V)	3.6
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Industrial
Packing Method	Tube
Pin Count	18
Standard Package Method	SOP
Original Package	SOIC W
Terminal Form	Surface Mount
Package Height	2.05(Min)
Package Length	11.55
Package Width	7.5
PCB changed	18
