ATSAMA5D26B-CU

SKU: 100747

Manufacturer: Microchip Technology

MPU RISC 32bit 500MHz 289-Pin LFBGA Tray

1960 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	3A991a.2.
Part Status	Obsolete
HTS	8542.31.00.01
Automotive	No
PPAP	No
Instruction Set Architecture	RISC
Device Core	ARM Cortex A5
Core Architecture	ARM
Number of CPU Cores	1
Data Bus Width (bit)	32
Instruction Cache Size	32KB
On-Chip Memory	128KB/SRAM
Maximum Speed (MHz)	500
Interface Type	CAN/Ethernet/I2C/I2S/SPI/UART/USB
UART	10
USART	0
Data Cache Size	32KB
USB	2
Multiply Accumulate	No
SPI	7
I2C	7
I2S	2
CAN	2
Memory Card Interface	SD/MMC
Ethernet	1
Ethernet Interface Type	MII/RMII
Ethernet Speed	10Mbps/100Mbps
Operating Supply Voltage-Min (V)	1.1
Typical Operating Supply Voltage (V)	1.2
Operating Supply Voltage-Max (V)	1.32
Maximum Power Dissipation (mW)	1149
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Industrial
Packing Method	Tray
Original Package	LFBGA
Pin Count	289
Standard Package Method	BGA
Terminal Form	Surface Mount
Package Height	1.03(Max)
Package Length	14
Package Width	14
PCB changed	289
