ATF22V10CQZ-20XU

SKU: 109806

Manufacturer: Microchip Technology

SPLD ATF22V10CQZ Family 500 Gates 10 Macro Cells 50MHz 5V 24-Pin TSSOP Tube

17790 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Family Name	ATF22V10CQZ
Device System Gates	500
Maximum Number of User I/Os	10
Number of Macro Cells	10
Product Terms	16
Programmability	Yes
Reprogrammability Support	Yes
In-System Programmability	No
Opr. Frequency (MHz)	50
Maximum Propagation Delay Time (ns)	20
Speed Grade	20
Operating Supply Voltage-Min (V)	4.5
Typical Operating Supply Voltage (V)	5
Operating Supply Voltage-Max (V)	5.5
Maximum Operating Current (mA)	80
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Industrial
Packing Method	Tube
Tradename	ATF22V10
Pin Count	24
Standard Package Method	SOP
Original Package	TSSOP
Terminal Form	Surface Mount
Package Height	0.95(Max)
Package Length	7.8
Package Width	4.48(Max)
PCB changed	24
