A3P400-FGG144I

SKU: 79326

Manufacturer: Microchip Technology

FPGA ProASIC®3 Family 400K Gates 231MHz 130nm Technology 1.5V 144-Pin FBGA Tray

2070 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.31.00.01
Automotive	No
PPAP	No
Family Name	ProASIC®3
Process Technology	130nm
User I/Os	97
Number of I/O Banks	4
Number of Inter Dielectric Layers	7
Number of Registers	9216
Operating Supply Voltage (V)	1.5
Device System Gates	400000
Program Memory Type	FLASH
Embedded Memory (Kbit)	54
Total Number of Block RAM	12
Device Logic Gates	400000
Number of Global Clocks	18
Device Number of DLLs/PLLs	1
Maximum Supply Current (mA)	30
JTAG Support	Yes
Programmability	Yes
Reprogrammability Support	Yes
Copy Protection	No
Opr. Frequency (MHz)	231
In-System Programmability	Yes
Speed Grade	STD
Differential I/O Standards	LVDS
Single-Ended I/O Standards	LVTTL
Maximum Differential I/O Pairs	25
Maximum I/O Performance	700Mbps
Operating Supply Voltage-Min (V)	1.425
Operating Supply Voltage-Max (V)	1.575
I/O Voltage (V)	1.5
Operating Temperature-Min	-40
Operating Temperature-Max	100
Supplier Temperature Grade	Industrial
Packing Method	Tray
Tradename	ProASIC
Original Package	FBGA
Pin Count	144
Standard Package Method	BGA
Terminal Form	Surface Mount
Package Height	1.05
Package Length	13
Package Width	13
PCB changed	144
