    DCW03A-12

    SKU: 61056
    Manufacturer: MEAN WELL
    Module DC-DC 12VIN 2-OUT 12V/-12V 0.125A/-0.125A 3W 8-Pin
    Download sample
    Request Free Samples
    1320 parts IN STOCK
    Shipped from :
    Netherlands
    Expected Ships :
    Rohs State : Need to verify

    QUANTITY

    Increments of 0 pcs
    Products specifications
    EU RoHS Compliant
    Part Status Obsolete
    HTS 8542.39.00.01
    Automotive No
    PPAP No
    Type Inverting
    Number of Outputs 2
    Isolation Isolated
    Minimum Input Voltage (V) 9
    Typical Input Voltage (V) 12
    Maximum Input Voltage (V) 18
    Output Voltage (V) -12
    Output Current (A) -0.125
    Output Power (W) 3
    Minimum Isolation Voltage 1000VDC
    Input/Output Type DC/DC
    Switching Frequency (kHz) 50(Min)
    Switching Regulator Yes
    Load Regulation 0.5%
    Line Regulation 0.5%
    Efficiency (%) 80(Typ)
    Operating Temperature-Min -40
    Operating Temperature-Max 71
    Product Weight (g) 15
    Output Type Fixed
    Pin Count 8
    Terminal Form Through Hole
    Package Height 12.2
    Package Length 31.8
    Package Width 20.3
    • DCW03A-12 Price
    • DCW0 Series
    • DCW03A-12 Datasheet
    • DCW03A-12 Application
    • DCW03A-12 Pdf
    • DCW03A-12 Pinout
    • DCW03A-12 Image
    • DCW03A-12 Picture
    • DCW03A-12 In Stock
    • DCW03A-12 Distributor
    • DCW03A-12 Switching Regulator Modules & DC to DC Converters
    • DCW03A-12 MEAN WELL
    Products specifications
    EU RoHS Compliant
    Part Status Obsolete
    HTS 8542.39.00.01
    Automotive No
    PPAP No
    Type Inverting
    Number of Outputs 2
    Isolation Isolated
    Minimum Input Voltage (V) 9
    Typical Input Voltage (V) 12
    Maximum Input Voltage (V) 18
    Output Voltage (V) -12
    Output Current (A) -0.125
    Output Power (W) 3
    Minimum Isolation Voltage 1000VDC
    Input/Output Type DC/DC
    Switching Frequency (kHz) 50(Min)
    Switching Regulator Yes
    Load Regulation 0.5%
    Line Regulation 0.5%
    Efficiency (%) 80(Typ)
    Operating Temperature-Min -40
    Operating Temperature-Max 71
    Product Weight (g) 15
    Output Type Fixed
    Pin Count 8
    Terminal Form Through Hole
    Package Height 12.2
    Package Length 31.8
    Package Width 20.3
