SP707CU-L

SKU: 31041

Manufacturer: MaxLinear, Inc

Processor Supervisor 4.65V 1 Active High/Active Low Automotive 8-Pin MSOP

3750 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
Automotive	Unknown
PPAP	Unknown
Number of Supervisors	1
Maximum Reset Active Time (ms)	200(Typ)
Output Driver	Active High/Active Low
Minimum Reset Threshold Voltage (V)	4.5
Typical Reset Threshold Voltage (V)	4.65
Maximum Reset Threshold Voltage (V)	4.75
Monitored Voltage (V)	4.65
Operating Supply Voltage-Min (V)	1.1
Operating Supply Voltage-Max (V)	5.5
Maximum Supply Current (uA)	40(Typ)
Maximum Power Dissipation (mW)	330
Power Fail Detection	Yes
Watchdog Timer	No
Manual Reset	Yes
Chip Enable Signals	No
Battery Backup Switching	No
Operating Temperature-Min	0
Operating Temperature-Max	70
Type	Voltage Supervisory
Pin Count	8
Standard Package Method	MSOP
Original Package	MSOP
Terminal Form	Surface Mount
Package Height	0.85
Package Length	3
Package Width	3
PCB changed	8
