MAX4564EKA+T

SKU: 69874

Manufacturer: Maxim Integrated

Analog Switch Single SPDT 8-Pin SOT-23 T/R

21960 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Type	Analog Switch
Configuration	Single SPDT
Switch Architecture	SPDT
Number of Channels per Chip	1
Number of Inputs per Chip	1
Number of Outputs per Chip	2
Chip Enable Signals	Yes
Polarity	Non-Inverting
Maximum Propagation Delay Bus to Bus (ns)	70@±6V
Maximum Turn-On Time (ns)	250@3.3V
Maximum Turn-Off Time (ns)	110@3.3V
Maximum Frequency (25°C) @ Vcc (MHz)	450(Typ)@±6V
Input Signal Type	Single
Output Signal Type	Single
Minimum Single Supply Voltage (V)	1.8
Typical Single Supply Voltage (V)	3
Maximum Single Supply Voltage (V)	12
Minimum Dual Supply Voltage (V)	±1.8
Typical Dual Supply Voltage (V)	±3
Maximum Dual Supply Voltage (V)	±6
Typical Supply Current (mA)	0.0000001@5.5V
Maximum Supply Current (mA)	0.001@5.5V
Maximum Low Level Output Current (mA)	20
Maximum High Level Output Current (mA)	20
Maximum On Resistance (Ohm)	275@2.7V
Maximum On Resistance Range (Ohm)	250 to 400
Propagation Delay Test Condition (pF)	35
Power Supply Type	Dual
Maximum Power Dissipation (mW)	444.4
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Extended
Packing Method	Tape and Reel
Pin Count	8
Standard Package Method	SOT-23
Original Package	SOT-23
Terminal Form	Surface Mount
Package Height	1.1
Package Length	2.9
Package Width	1.63
PCB changed	8
