LXZ1-PM01

SKU: 154704

Manufacturer: Lumileds

LED Uni-Color Green Automotive 2-Pin SMD Module T/R

2630 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.40.20.00
Automotive	Unknown
PPAP	Unknown
Type	Uni-Color
Product Category	Chip LED
Color	Green
Number of LEDs	1
LED Body Material	InGaN
Lens Shape Type	Rectangular
Mounting Orientation	Top Mount
Luminous Flux	118lm
Dominant Wavelength (nm)	540(Max)
Viewing Angle (°)	125
Maximum Forward Current (mA)	1000
Test Current (mA)	500
Maximum Forward Voltage (V)	3.5
Minimum Forward Voltage (V)	2.5
Typical Forward Voltage (V)	3.27
Maximum Junction Temperature (°C)	150
Internal Protection	No
Maximum Case Temperature (°C)	135
Operating Temperature-Min	-40
Operating Temperature-Max	135
Lead Standoff	No
Supplier Color	Green
High Power	Yes
High Brightness	Yes
Packing Method	Tape and Reel
Original Package	SMD Module
Pin Count	2
Terminal Form	Surface Mount
Package Length	1.7
Package Width	1.3
