LXZ1-PD01

SKU: 48567

Manufacturer: Lumileds

LED Uni-Color Red Automotive 2-Pin SMD Module T/R

1800 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.40.20.00
Automotive	Unknown
PPAP	Unknown
Type	Uni-Color
Product Category	Chip LED
Color
Number of LEDs	1
LED Body Material	AlInGaP
Lens Shape Type	Rectangular
Mounting Orientation	Top Mount
Luminous Flux	52lm
Dominant Wavelength (nm)	630(Max)
Viewing Angle (°)	145
Maximum Forward Current (mA)	700
Test Current (mA)	500
Maximum Forward Voltage (V)	2.75
Minimum Forward Voltage (V)	1.75
Typical Forward Voltage (V)	2.2
Maximum Junction Temperature (°C)	150
Internal Protection	No
Maximum Case Temperature (°C)	120
Operating Temperature-Min	-40
Operating Temperature-Max	120
Lead Standoff	No
Supplier Color	Red
High Power	Yes
High Brightness	Yes
Packing Method	Tape and Reel
Original Package	SMD Module
Pin Count	2
Terminal Form	Surface Mount
Package Height	0.9
Package Length	1.7
Package Width	1.3
