MDD95-22N1B

SKU: 147924

Manufacturer: Littelfuse

Rectifier Diode Schottky 2.2KV 120A 3-Pin TO-240AA Box

860 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.10.00.80
Automotive	No
PPAP	No
Type	Schottky Diode
Configuration	Dual Series
Peak Reverse Repetitive Voltage (V)	2200
Maximum Continuous Forward Current (A)	120
Peak Non-Repetitive Surge Current (A)	3030
Peak Forward Voltage (V)	1.43@300A
Peak Reverse Current (uA)	200
Maximum Power Dissipation (mW)	481000
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Box
Original Package	TO-240AA
Pin Count	3
Terminal Form	Screw
Package Height	30
Package Length	92
Package Width	20.8
