DSS2X41-01A

SKU: 146026

Manufacturer: Littelfuse

Rectifier Diode Schottky 100V 40A 4-Pin SOT-227B Tube

1320 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.10.00.80
Automotive	No
PPAP	No
Type	Schottky Diode
Configuration	Dual Parallel
Peak Reverse Repetitive Voltage (V)	100
Maximum Continuous Forward Current (A)	40
Peak Non-Repetitive Surge Current (A)	450
Peak Forward Voltage (V)	1.05@80A
Peak Reverse Current (uA)	1000
Maximum Power Dissipation (mW)	110000
Operating Temperature-Min	-40
Operating Temperature-Max	150
Packing Method	Tube
Original Package	SOT-227B
Pin Count	4
Standard Package Method	SOT
Terminal Form	Screw
Package Length	38.23(Max)
Package Width	25.42(Max)
PCB changed	4
