0157005.DR

SKU: 6540

Manufacturer: Littelfuse

Fuse Chip Very Fast Acting 5A 125V Holder Clip 6.5 X 3.7 X 3.9mm Ceramic T/R PSE/cULus

3090 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8536.10.00.40
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Type	Chip
Acting	Very Fast
Application	Base Station
Fuse Size (mm)	6.5 X 3.7 X 3.9
Current Rating (A)	5
Voltage Rating (V)	125
Maximum AC Voltage Rating (V)	125
Maximum DC Voltage Rating (V)	125
Breaking Capacity @ Rated Voltage (A)	50@125VAC
Typical Melting I2t (A²S)	5.566
Typical Cold Resistance (Ohm)	0.0127
Terminal Form	Clip
Number of Terminals	2
Operating Temperature-Min	-55
Operating Temperature-Max	125
Packing Method	Tape and Reel
Depth (mm)	3.7
Length (mm)	6.5
Height (mm)	3.9
Fuse Body Material	Ceramic
