M4A3-384/192-10FANC

SKU: 94230

Manufacturer: Lattice Semiconductor

CPLD ispMACH 4A Family 15K Gates 384 Macro Cells 83.3MHz/118MHz 3.3V 256-Pin FBGA Tray

1280 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	NRND
HTS	8542.31.00.01
Automotive	No
PPAP	No
Family Name	ispMACH 4A
Program Memory Type	EEPROM
Number of Global Clocks	4
Number of Macro Cells	384
Product Terms	20
Device System Gates	15000
Data Gate	No
Maximum Number of User I/Os	192
Number of Flip Flops	576
In-System Programmability	Yes
Programmability	Yes
Reprogrammability Support	Yes
Maximum Internal Frequency (MHz)	125
Maximum Clock to Output Delay (ns)	6
Maximum Propagation Delay Time (ns)	10
Speed Grade	10
Individual Output Enable Control	Yes
Operating Supply Voltage-Min (V)	3
Operating Supply Voltage-Max (V)	3.6
Typical Operating Supply Voltage (V)	3.3
Tolerant Configuration Interface Voltage (V)	5
Operating Temperature-Min	0
Operating Temperature-Max	70
Supplier Temperature Grade	Commercial
Packing Method	Tray
Tradename	ispMACH
Original Package	FBGA
Pin Count	256
Standard Package Method	BGA
Terminal Form	Surface Mount
Package Height	1.2
Package Length	17
Package Width	17
PCB changed	256
