W2F15C1028AT1F

SKU: 137478

Manufacturer: KYOCERA AVX Components Corporation

Cap Feed Through 0.001uF 50VDC X7R -20% to 50% Flat 0805 125°C Automotive

3820 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8532.24.00.20
Automotive	Yes
PPAP	Unknown
Capacitance Value	0.001uF
Tolerance	-20% to 50%
Voltage	50VDC
IR (mA)	300
Minimum Insulation Resistance (Ohm)	1G
Dielectric	X7R
Microwave Application	No
Special Features	Excellent Decoupling Capability
Construction	Flat
Terminal Form	Surface Mount
Maximum Terminal Width (mm)	1.45
Case Code - in	0805
Operating Temperature-Min	-55
Operating Temperature-Max	125
Length (mm)	2.01
Depth (mm)	1.25
Height (mm)	1.14(Max)
Length Tolerance (mm)	±0.2
