MOC3021X

SKU: 155234

Manufacturer: Isocom Components

Optocoupler Triac AC-OUT 1-CH 400V 6-Pin PDIP

2220 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.40.80.00
Automotive	No
PPAP	No
Number of Channels per Chip	1
Zero-Crossing Circuit	No
Standard	UL
Output Device	Triac
Output Type	AC
Maximum Output Voltage (VAC)	280
Minimum Isolation Voltage (Vrms)	5300
Typical Forward Voltage (V)	1.2
Maximum Forward Voltage (V)	1.5
Repetitive Peak Off-State Voltage (V)	400
Maximum Reverse Voltage (V)	6
Typical Critical Rate of Rise of Off-State Voltage (V/us)	10
Maximum Forward Current (mA)	50
Minimum Trigger Current (mA)	15(Max)
Repetitive Peak Off-State Current (uA)	0.1
Maximum Power Dissipation (mW)	330
Operating Temperature-Min	-40
Operating Temperature-Max	100
Standard Package Method	DIP
Original Package	PDIP
Pin Count	6
Terminal Form	Through Hole
Package Height	4(Max)
Package Length	7.62(Max)
Package Width	7(Max)
PCB changed	6
