IS61LV256AL-10JLI-TR

SKU: 89780

Manufacturer: Integrated Silicon Solution Inc

SRAM Chip Async Single 3.3V 256K-bit 32K x 8 10ns 28-Pin SOJ T/R

137740 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.32.00.41
Automotive	No
PPAP	No
Chip Density (bit)	256K
Number of Words	32K
Number of Bits/Word (bit)	8
Data Rate Architecture	SDR
Address Bus Width (bit)	15
Number of Ports	1
Timing Type	Asynchronous
Max. Access Time (ns)	10
Process Technology	CMOS
Operating Supply Voltage-Min (V)	3.135
Typical Operating Supply Voltage (V)	3.3
Operating Supply Voltage-Max (V)	3.63
Operating Current (mA)	35
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Industrial
Packing Method	Tape and Reel
Original Package	SOJ
Pin Count	28
Standard Package Method	SOJ
Terminal Form	Surface Mount
Package Height	2.67(Max)
Package Length	18.54(Max)
Package Width	7.75(Max)
PCB changed	28
