2201

SKU: 6067

Manufacturer: Grayhill

Switch Push Button N.O. SPST Round Plunger 10A 220VAC Momentary Contact Solder Lug Panel Mount

3050 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8536.50.90.65
Automotive	No
PPAP	No
Switch Function	Momentary Contact
Pole Throw Configuration	SPST
Actuator Style	Round Plunger
Switch Configuration	N.O.
Bushing Type	Threaded
Current Rating-Max(A)	10@115VAC
Dielectric Strength	1000VAC
Minimum Insulation Resistance (MOhm)	1000
Maximum Contact Resistance (mOhm)	<=25
Actuator Color	Red
Actuator Length (mm)	6.93
Terminal Form	Panel Mount
Terminal Form	Solder Lug
Number of Terminals	2
Housing Body Material	Thermoset Plastic
Body Orientation	Straight
Operating Temperature-Min	-40
Operating Temperature-Max	85
Thread Size	15/32-32
Length (mm)	22.35
Depth (mm)	22.35
