B82432A1105J

SKU: 46434

Manufacturer: EPCOS (TDK)

Inductor General Purpose Chip Molded Wirewound 1000uH 5% 100KHz 30Q-Factor Ferrite 0.055A 32Ohm DCR 1812 Automotive T/R

1190 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
Automotive	Yes
PPAP	Unknown
Type	General Purpose Chip
Technology	Wirewound
Protection Style	Molded
Core Body Material	Ferrite
Inductance (H)	1000u
Tolerance	5%
Inductance Test Frequency (Hz)	100K
Maximum DC Current (A)	0.055
Maximum Saturation Current (A)	0.055
Maximum DC Resistance (Ohm)	32
Minimum Quality Factor	30
Quality Test Frequency (Hz)	796K
Minimum Self Resonant Frequency (Hz)	2.3M
Number of Terminals	2
Case Size	1812
Operating Temperature-Min	-55
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	4.8
Depth (mm)	3.5
