B82432A1103K

SKU: 109912

Manufacturer: EPCOS (TDK)

Inductor General Purpose Chip Molded Wirewound 10uH 10% 1MHz 45Q-Factor Ferrite 0.32A 0.98Ohm DCR 1812 Automotive T/R

2160 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8504.50.80.00
Automotive	Yes
PPAP	Unknown
Type	General Purpose Chip
Technology	Wirewound
Protection Style	Molded
Core Body Material	Ferrite
Inductance (H)	10u
Tolerance	10%
Inductance Test Frequency (Hz)	1M
Maximum DC Current (A)	0.32
Maximum Saturation Current (A)	0.32
Maximum DC Resistance (Ohm)	0.98
Minimum Quality Factor	45
Quality Test Frequency (Hz)	2.52M
Minimum Self Resonant Frequency (Hz)	22M
Number of Terminals	2
Case Size	1812
Operating Temperature-Min	-55
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	4.8
Terminal Form	Surface Mount
Depth (mm)	3.5
