2N7002W

SKU: 5495

Manufacturer: Diotec Semiconductor AG

Trans MOSFET N-CH 60V 0.115A 3-Pin SOT-323 T/R

42920 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Product Category	Small Signal
Configuration	Single
Channel Mode	Enhancement
Channel Type	N
Number of Elements per pcs	1
Maximum Drain Source Voltage (V)	60
Maximum Gate Source Voltage (V)	±20
Maximum Continuous Drain Current (A)	0.115
Maximum Drain Source Resistance (mOhm)	13500@10V
Typical Input Capacitance @ Vds (pF)	50@25V
Maximum Power Dissipation (mW)	200
Operating Temperature-Min	-55
Operating Temperature-Max	150
Supplier Temperature Grade	Commercial
Original Package	SOT-323
Pin Count	3
Terminal Form	Surface Mount
Package Length	2
Package Width	1.25
