SBR8E20P5-7

SKU: 70818

Manufacturer: Diodes Incorporated

Rectifier Diode Super Barrier Rectifier 20V 8A 3-Pin(3+Tab) PowerDI 5 T/R

1700 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8541.10.00.80
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Type	Super Barrier Rectifier
Configuration	Single Dual Anode
Peak Reverse Repetitive Voltage (V)	20
Maximum Continuous Forward Current (A)	8
Peak Non-Repetitive Surge Current (A)	180
Peak Forward Voltage (V)	0.45
Peak Reverse Current (uA)	500
Operating Temperature-Min	-55
Operating Temperature-Max	150
Packing Method	Tape and Reel
Supplier Temperature Grade	Automotive
Original Package	PowerDI 5
Pin Count	3
Terminal Form	Surface Mount
Package Height	1.1(Max)
Package Length	3.97
Package Width	5.37
PCB changed	3
