PI6C2408-1WIE

SKU: 115695

Manufacturer: Diodes Incorporated

Zero Delay Buffer 8-Out Single-Ended 16-Pin SOIC Tube

2060 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
Automotive	No
PPAP	No
Type	Clock Multiplier
Number of Inputs	1
Number of Outputs	8
Number of Banks	2
Programmability	No
Minimum Output Frequency (MHz)	10
Maximum Output Frequency (MHz)	140
Maximum Cycle to Cycle Jitter (ps)	150
Maximum Output Skew (ps)	250
Maximum Fall Time (ns)	2.2
Maximum Rise Time (ns)	2.5
Spread Spectrum	No
Maximum Duty Cycle (%)	60
Input Signal Type	Single-Ended
Output Signal Type	Single-Ended
Operating Supply Voltage-Min (V)	3.135
Typical Operating Supply Voltage (V)	3.3
Operating Supply Voltage-Max (V)	3.465
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Industrial
Packing Method	Tube
Standard Package Method	SOP
Original Package	SOIC
Pin Count	16
Terminal Form	Surface Mount
Package Height	1(Min)
Package Length	9.9
Package Width	3.9
PCB changed	16
