DMN2013UFX-7

SKU: 129325

Manufacturer: Diodes Incorporated

Trans MOSFET N-CH 20V 10A 6-Pin WDFN EP T/R

3520 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Configuration	Dual
Channel Mode	Enhancement
Channel Type	N
Number of Elements per pcs	2
Maximum Drain Source Voltage (V)	20
Maximum Gate Source Voltage (V)	±8
Maximum Gate Threshold Voltage (V)	1.1
Maximum Continuous Drain Current (A)	10
Maximum Gate Source Leakage Current (nA)	10000
Maximum IDSS (uA)	1
Maximum Drain Source Resistance (mOhm)	11.5@4.5V
Typical Gate Charge @ Vgs (nC)	57.4@8V
Typical Input Capacitance @ Vds (pF)	2607@10V
Maximum Power Dissipation (mW)	2140
Typical Fall Time (ns)	13.7
Typical Rise Time (ns)	20.3
Typical Turn-Off Delay Time (ns)	42.5
Typical Turn-On Delay Time (ns)	8.6
Operating Temperature-Min	-55
Operating Temperature-Max	150
Packing Method	Tape and Reel
Original Package	WDFN EP
Pin Count	6
Standard Package Method	DFN
Terminal Form	Surface Mount
Package Height	0.88
Package Length	2
Package Width	5
PCB changed	6
