APT27HZTR-G1

SKU: 102649

Manufacturer: Diodes Incorporated

Trans GP BJT NPN 450V 0.8A 3-Pin TO-92 Ammo

2820 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Obsolete
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Type	NPN
Product Category	Bipolar Power
Configuration	Single
Number of Elements per pcs	1
Collector-Emitter Voltage-Max (V)	450
Maximum Emitter Base Voltage (V)	9
Maximum Collector-Emitter Saturation Voltage (V)	0.5@40mA@200mA
Maximum DC Collector Current (A)	0.8
Minimum DC Current Gain	15@100mA@10V
Maximum Power Dissipation (mW)	800
Operating Temperature-Min	-55
Operating Temperature-Max	150
Packing Method	Ammo
Original Package	TO-92
Pin Count	3
Standard Package Method	TO-92
Terminal Form	Through Hole
Package Height	4.7(Max)
Package Length	4.8(Max)
Package Width	3.8(Max)
