MB96F696RBPMC-GSAE1

SKU: 62958

Manufacturer: Cypress - An Infineon Technologies Company

MCU 16-bit F2MC-16FX RISC 288.5KB Flash 3.3V/5V Tray

1880 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	3A991.a.3
Part Status	Obsolete
HTS	8542.31.00.01
Automotive	No
PPAP	No
Family Name	F2MC
Instruction Set Architecture	RISC
Device Core	F2MC-16FX
Core Architecture	F2MC
Maximum CPU Frequency (MHz)	32
Maximum Clock Rate (MHz)	32
Data Bus Width (bit)	16
Program Memory Type	FLASH
Program Memory Size	288KB
RAM Size	16KB
Programmability	Yes
Interface Type	CAN/I2C/USART
Number of I/Os	79
No. of Timers	5
PWM	8
Number of ADCs	Single
ADC Channels	27
ADC Resolution (bit)	10
LCD Segments	144
USART	5
UART	0
USB	0
SPI	0
I2C	1
I2S	0
CAN	1
Ethernet	0
Watchdog	1
Special Features	CAN Controller,LCD Controller
Operating Supply Voltage-Min (V)	2.7
Typical Operating Supply Voltage (V)	3.3
Operating Supply Voltage-Max (V)	5.5
Operating Temperature-Min	-40
