HLMP-Q106-R0011

SKU: 136565

Manufacturer: Broadcom Inc

LED Low-Power Uni-Color Deep Red 654nm 2V 2-Pin T/R

2140 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.40.20.00
Automotive	No
PPAP	No
Type	Uni-Color
Product Category	Chip LED
Color
Number of LEDs	1
LED Body Material	GaAlAs
Lens Shape Type	Circular
Lens Dimensions (mm)	1.91x1.91x1.4
Lens Appearance	Colorless Non Diffused
Mounting Orientation	Top Mount
Intensity	400mcd
Dominant Wavelength (nm)	644
Peak Wavelength (nm)	654
Viewing Angle (°)	15
Maximum Forward Current (mA)	50
Test Current (mA)	20
Maximum Forward Voltage (V)	1.9
Reverse Voltage (V)	5(Max)
Typical Forward Voltage (V)	2
Maximum Junction Temperature (°C)	110
Internal Protection	No
Maximum Power Dissipation (mW)	100
Operating Temperature-Min	-55
Operating Temperature-Max	100
Lead Standoff	No
Capacitance Value (pF)	20
Supplier Color	Deep Red
Special Color	Deep Red
High Power	No
High Brightness	No
Packing Method	Tape and Reel
Pin Count	2
Terminal Form	Through Hole
Package Height	2.21(Max)
Package Length	2.34(Max)
Package Width	2.92(Max)
