SRU1038-680Y

SKU: 21762

Manufacturer: Bourns

Inductor Power Shielded Wirewound 68uH 30% 100KHz 24Q-Factor Ferrite 1.3A 0.166Ohm DCR T/R

4420 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8504.50.80.00
Automotive	Unknown
Type	Power
Technology	Wirewound
Protection Style	Shielded
Core Body Material	Ferrite
Inductance (H)	68u
Tolerance	30%
Inductance Test Frequency (Hz)	100K
Maximum DC Current (A)	1.3
Maximum Saturation Current (A)	1.3(Typ)
Maximum DC Resistance (Ohm)	0.166
Minimum Quality Factor	24
Quality Test Frequency (Hz)	2.52M
Minimum Self Resonant Frequency (Hz)	7M(Typ)
Number of Terminals	2
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	10.3
Terminal Form	Surface Mount
Depth (mm)	10.3
