SRR1260A-101M

SKU: 156373

Manufacturer: Bourns

Inductor Power Shielded Wirewound 100uH 20% 1KHz 26Q-Factor Ferrite 1.7A 0.18Ohm DCR Automotive T/R

1250 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8504.50.80.00
Automotive	Yes
PPAP	Yes
Type	Power
Technology	Wirewound
Protection Style	Shielded
Core Body Material	Ferrite
Inductance (H)	100u
Inductance Decrease Percentage @ Isat (%)	25
Tolerance	20%
Inductance Test Frequency (Hz)	1K
Maximum DC Current (A)	1.7(Typ)
Maximum Saturation Current (A)	1.7(Typ)
Maximum DC Resistance (Ohm)	0.18
Minimum Quality Factor	26
Quality Test Frequency (Hz)	796K
Minimum Self Resonant Frequency (Hz)	6.07M(Typ)
Number of Terminals	2
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	12.8
Terminal Form	Surface Mount
Depth (mm)	12.8
