SRR1260-4R7Y

SKU: 57349

Manufacturer: Bourns

Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 19Q-Factor Ferrite 6.8A 0.0155Ohm DCR T/R

61430 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8504.50.80.00
Automotive	No
PPAP	No
Type	Power
Technology	Wirewound
Protection Style	Shielded
Core Body Material	Ferrite
Inductance (H)	4.7u
Inductance Decrease Percentage @ Isat (%)	25
Tolerance	30%
Inductance Test Frequency (Hz)	100K
Maximum DC Current (A)	6.8
Maximum Saturation Current (A)	7(Typ)
Maximum DC Resistance (Ohm)	0.0155
Minimum Quality Factor	19(Typ)
Quality Test Frequency (Hz)	7.96M
Minimum Self Resonant Frequency (Hz)	36.7M(Typ)
Number of Terminals	2
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	12.8
Terminal Form	Surface Mount
Depth (mm)	12.8
