SDE1006A-150M

SKU: 56840

Manufacturer: Bourns

Inductor Power Unshielded Wirewound 15uH 20% 1MHz Ferrite 3.4A 0.08Ohm DCR Automotive T/R

3470 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8504.50.80.00
Automotive	Yes
PPAP	Yes
Type	Power
Technology	Wirewound
Protection Style	Unshielded
Core Body Material	Ferrite
Inductance (H)	15u
Tolerance	20%
Inductance Test Frequency (Hz)	1M
Maximum DC Current (A)	3.4(Typ)
Maximum Saturation Current (A)	3.6(Typ)
Maximum DC Resistance (Ohm)	0.08
Minimum Self Resonant Frequency (Hz)	19.8M(Typ)
Number of Terminals	2
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	10.4
Terminal Form	Surface Mount
Depth (mm)	9.4
