CC453232-680KL

SKU: 103065

Manufacturer: Bourns

Inductor General Purpose Chip Wirewound 68uH 10% 2.52MHz 10Q-Factor Ferrite 0.22A 2.6Ohm DCR 1812 T/R

2300 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Type	General Purpose Chip
Technology	Wirewound
Core Body Material	Ferrite
Inductance (H)	68u
Tolerance	10%
Inductance Test Frequency (Hz)	2.52M
Maximum DC Current (A)	0.22
Maximum DC Resistance (Ohm)	2.6
Minimum Quality Factor	10
Quality Test Frequency (Hz)	2.52M
Minimum Self Resonant Frequency (Hz)	10M
Number of Terminals	2
Case Size	1812
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	4.8
Terminal Form	Surface Mount
Depth (mm)	3.4
