2017-09-SMC-RPLF

SKU: 8602

Manufacturer: Bourns

Gas Discharge Tubes 90VDC 10kADC 10AAC 3pF Solder Pad SMD

3160 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
DC Sparkover Voltage Tolerance	±20%
Maximum Impulse Sparkover Voltage @ 100V/s (V)	450
Typical DC Sparkover Voltage @ 100V/s (V)	90
Typical Impulse Discharge Current @ 8/20us @ 10Times (kA)	10
Typical AC Discharge Current @ 1s @ <= 10Times (A)	10
Minimum Insulation Resistance @ 100V (GOhm)	1
Maximum Capacitance @ 1MHz (pF)	3
Number of Electrodes	2
Terminal Form	Solder Pad
Number of Terminals	2
Operating Temperature-Min	-55
Packing Method	Tape and Reel
Operating Temperature-Max	105
Length (mm)	8.5
Depth (mm)	4.5
Height (mm)	8
Failsafe Protection	No
