    LTM4609IY

    SKU: 23550
    Manufacturer: Analog Devices
    36VIN, 34VOUT High Efficiency Buck-Boost DC/DC μModule (Power Module) Regulator
    Download sample
    Request Free Samples
    3290 parts IN STOCK
    Shipped from :
    Netherlands
    Expected Ships :
    Rohs State : Need to verify

    QUANTITY

    Increments of 0 pcs
    Products specifications
    EU RoHS Not Compliant
    ECCN (US) EAR99
    Part Status Active
    HTS 8542.39.00.01
    SVHC Yes
    SVHC Exceeds Threshold Yes
    Automotive No
    PPAP No
    Type Step Down
    Number of Outputs 1
    Isolation Non-Isolated
    Minimum Input Voltage (V) 4.5
    Maximum Input Voltage (V) 36
    Output Voltage (V) 0.8 to 34
    Output Current (A) 10(Typ)
    Input/Output Type DC/DC
    Typical Standby Current (mA) 0.035
    Switching Frequency (kHz) 440
    Switching Regulator Yes
    Load Regulation 0.5%
    Line Regulation 0.02%/V
    Efficiency (%) 98
    On/Off Logic Positive
    Operating Temperature-Min -40
    Operating Temperature-Max 85
    Supplier Temperature Grade Industrial
    Packing Method Tray
    Product Weight (g) 1.7
    Output Type Adjustable
    Original Package BGA
    Pin Count 141
    Standard Package Method BGA
    Terminal Form Surface Mount
    Package Height 2.82
    Package Length 15
    Package Width 15
    PCB changed 141
